EZP2019+ High Speed USB SPI Programmer Support 24 25 93 EEPROM Flash Bios Chips
EZP2019+ High Speed USB SPI Programmer Support 24 25 93 EEPROM Flash Bios Chips
Product Description:
Software and firmware update.
Surpport 25 FLASH, 24 EEPROM, 25 EEPROM, 93 EEPROM,etc.
Small shape. small size and weight light and low power loss.
Working with Windows 2000, Windows XP, Windows Vista, Windows 7(32bit & 64bit).
USB 2.0 interface, the speed is 12Mbps.
The speed of reading and writing is very fast.
Auto select power votage.
Auto detect chip modles.
Auto off-line chip copy.
Read and Write the bios chips of DVD,TV,PC,harddisk,etc.
Package include:
1* EZP2013 Programmer
1* USB2.0 12Mbps Interface
1* CD with PDF file and install file
1* 150mil SOP8 to DIP8 Socket
1* 200-208mil SOP8 to DIP8 Socket
1* SOP16-DIP8 (300mil)
2* Simple SMD PIN8 DIP
1* 1.8V Conversion adapter
1* TSSOP16/8 Socket
1* SOP8 Clip
1* LED LCD 2IN1 Cable
1* QFN8/WSNO8 PCB converter adapter
For Now support All 24，25，93 Series IC
********************25 SPI FLASH*******************************************************************
AMIC: A25L05PU, A25L05PT,A25L10PT,A25L05PU,A25L20PT,A25L512, A25L010,
A25L10P, A25L020, A25L20P, A25L040, A25L40P, A25L080, A25L80P, A25L016, A25L16P, A25L032,A25LQ32A
ATMEL: AT25F512, AT25F512A, AT25F512B, AT25F1024, AT25F1024A, AT25FS010,
AT25DF021, AT25F2048, AT25DF041A, AT25F4096, AT25FS040, AT26F004, AT26DF081A,
AT25DF161, AT26DF161, AT26DF161A, AT25DF321, AT25DF321A, AT26DF321
EON: EN25F05, EN25LF05, EN25P05, EN25D10, EN25F10, EN25LF10, EN25P10, EN25D20, EN25B05,EN25B05T,
EN25F20, EN25LF20, EN25D40, EN25F40, EN25LF40, EN25D80, EN25F80, EN25Q80, EN25T80,EN25T80,
EN25B16, EN25B16T, EN25D16, EN25F16, EN25Q16, EN25T16, EN25B32, EN25B32T, EN25F32,EN25QH16,
EN25P32, EN25Q32, EN25B64, EN25B64T, EN25F64, EN25P64, EN25Q64, EN25F128, EN25Q128
ES: ES25P80, ES25P16,
ESMT: F25L004A, F25L04UA, F25L008A, F25L08PA, F25L016A, F25L16PA, F25L32PA, F25L32QA,F25L32QA
MXIC: MX25L512, MX25V512, MX25L1005, MX25L2005, MX25L4005A, MX25V4005, MX25L8005,
MX25V8005, MX25L1605D, MX25L1635D, MX25L3205D, MX25L3225D, MX25L3235D, MX25L3237D, MX25L6405D, MX25L12805D
KH25L4006E,KH25L8006E, KH25L80036, KH25L1606E, MX25V1005, MX25U4035, MX25V4035,MX25V8035,MX25U8935,
MX25L8006E,MX25L1606E,MX25L1635D, MX25L1633E,MX25L1635D, MX25L1608D, MX25L1608E, MX25U1635E,MX25L3225D
MX25L3237D,MX25L3236D,MX25L3206E, MX25L3235D,MX25U3235F, MX25U3235E, MX25L3208D,MX25L3208E,MX25L6455E,
MX25L6465E,MX25L6408D,MX25L6408E,MX25L6406E,MX25L6445E,MX25L6436E,MX25L12835E,MX25L12835F,MX25U12835F,
MX25L12845E,MX25L12836E,MX25L12865E,MX25L12855E,MX25L25635E,MX25L25635F,MX25L25639F,MX25L25735E,
MX25U25635F,MX25L25735F,MX66U51235F,MX66L51235F
NEXFLASH: NX25P10, NX25P20, NX25P40, NX25P80, NX25P16, NX25P32
PMC: PM25LV512A, PM25LV010A, PM25LV020, PM25LV040, PM25LV080B
SAIFUN: SA25F005, SA25F010, SA25F020, SA25F040, SA25F080, SA25F160, SA25F320
SPANSION: S25FL001,S25FL002,S25FL004A, S25FL008A, S25FL016A, S25FL032A, S25FL064A,S25FL0128
SST: SST25VF512, SST25VF512A, SST25VF010, SST25VF010A,
SST25VF020, SST25VF020A, SST25VF040, SST25VF040A, SST25VF040B, SST25VF080B,
SST25VF016B, SST25VF032B, SST25VF064C
GIGADEVICE: GD25Q512,GD25Q10,GD25Q20B,GD25Q21B,GD25Q40B,GD25Q41B,GD25LQ40,GD25F40,GD25F80,
GD25Q80,GD25Q16,GD25Q32B,GD25Q64,GD25Q128,GD25Q256,GD25Q256MC
ST: M25P05A, M25P10A, M25PE10, M25P20, M25PE20, M25P40, M25PE40, M25P80,
M25PE80, M25PX80, M25P16, M25PE16, M25PX16, M25P32, M25PX32, M25P64, M25PX64, M25P128
WINBOND: W25P10, W25X10, W25X10A, W25X10AL, W25X10L, W25P20, W25X20,
W25X20A, W25X20AL, W25X20L, W25P40, W25X40, W25X40A, W25X40AL, W25X40L,
W25P80, W25X80, W25X80A, W25X80AL, W25X80L, W25P16, W25X16, W25P32, W25X32, W25X64
W25Q40,W25Q80,W25Q16,W25Q32,W25Q64,W25Q128,W25Q64FV,W25Q64FW,W25Q256
********************24 EEPROM*******************************************************************
ATMEL: AT24C01, AT24C01A, AT24C01B, AT24C02, AT24C02A, AT24C02B, AT24C04, AT24C04A,
AT24C04B, AT24C08, AT24C08A, AT24C08B, AT24C16, AT24C16A, AT24C16B, AT24C32, AT24C32A,
AT24C32B, AT24C64, AT24C64A, AT24C64B, AT24C128, AT24C128A, AT24C128B, AT24C256, AT24C256A,
AT24C256B, AT24C512, AT24C512A, AT24C512B, AT24C1024, AT24C1024A, AT24C1024B
********************93 EEPROM*******************************************************************
ATMEL: AT93C46(16bit), AT93C46(16bit)-SOP8, AT93C46(8bit), AT93C46(8bit)-SOP8,
AT93C46A, AT93C56(16bit), AT93C56(16bit)-SOP8, AT93C56(8bit), AT93C56(8bit)-SOP8,
AT93C57(16bit), AT93C57(16bit)-SOP8, AT93C57(8bit), AT93C57(8bit)-SOP8, AT93C66(16bit),
AT93C66(16bit)-SOP8, AT93C66(8bit), AT93C66(8bit)-SOP8, AT93C86(16bit), AT93C86(16bit)-SOP8,
AT93C86(8bit), AT93C86(8bit)-SOP8
